Description JP Hobby’s electromagnetic control aircraft brake system is replacing and reshaping the traditional pneumatic and server remote control aircraft braking system. Electric Wheel and Brake Set 50mm – V2 with 5mm Axle and a 3/8″ Brake Flange (See Additional Photo) This will enable the players an easier installation mode and a better control on distance when landing without adding extra flying weight. Jingpin Hobby applies high grade aluminum machined brake Wheel frame , Built inside magnetic coil, high intensity hub with strong axle and adopting replaceable advanced hollow rubber tires skin. Feature: 1: Completely control by electricity , no more trouble from air brake air leaking. 2:Strong CNC machined wheel frame and inflatable true soft rubber tire. 3.The controller will shut down the brake after 1 minute automatically , The controller will smartly detect it if you the brake stop for 1 minutes, and automatically reset it to its normal function. Brake Using illustration: 1.Voltage input :7.2V-14.8V Can tap directly on aircraft batteries Or use an external battery 7.2V-14.8V 2.Signal input : Connect remote control receiver, set an action 3.Capacity control: adjustment clockwise will increase the power, or counter clockwise to reduce power 4.Brake wheel: Connect the power input line on the battery.Set come with two main wheels and brake controller. Specifications: 1.Main Wheel Diameter:50mm-65mm 2.Axle Screw Diameter: 5mm Brake Flange: 3/8″ (9.5mm) 3.Total Weight: 4.37 oz/ 135g Instruction Step 1: Install the magnetic wheels with your wheel strut. Step 2: Connect two brake wheels’ wire into PC-board, and the signal wire into the receiver : Step 3: Set an action “ON/OFF” on your transmitter: Notice :The signal wire must connect into the working receiver,otherwise it will consume all the battery. Voltage input: 7.2V-14.8V can tap directly on aircraft battery or use an external battery 7.2V-14.8V. Brake force control: The transmitter only support ON/OFF, thus there is not making proportional brake, or you can use currency trim button to control the brake force.The controller shut down the brake after 1 minute. The controller will smartly detect it,shut down the current to brake system and automatically reset it to its normal function. This ‘auto-shut down’ is designed to protect the magnetic coil and conserve your battery power.
