JP Hobby’s electromagnetic control aircraft brake system is replacing and reshaping the traditional pneumatic and server remote control aircraft braking system. Electric Wheel and Brake Set 60mm – 4mm Axle. . This will enable the players an easier installation mode and a better control on distance when landing without adding extra flying weight. . Jingpin Hobby applies high grade aluminum machined brake Wheel frame , Built inside magnetic coil, high intensity hub with strong axle and adopting replaceable advanced hollow rubber tires skin. . Feature:. 1: Completely control by electricity , no more trouble from air brake air leaking. 2:Strong CNC machined wheel frame and inflatable true soft rubber tire. 3.The controller will shut down the brake after 1 minute automatically , The controller will smartly detect it if you the brake stop for 1 minutes, and automatically reset it to its normal function. . Brake Using illustration:. 1.Voltage input :7.2V-14.8V Can tap directly on aircraft batteries Or use an external battery 7.2V-14.8V. 2.Signal input : Connect remote control receiver, set an action. 3.Capacity control: adjustment clockwise will increase the power, or counter clockwise to reduce power. 4.Brake wheel: Connect the power input line on the battery.Set come with two main wheels and brake controller. . Specifications:. 1.Main Wheel Diameter:50mm-65mm. 2.Axle Screw Diameter: 4mm. 3.Total Weight: 4.37 oz/ 135g. Instruction. Step 1: Install the magnetic wheels with your wheel strut. . Step 2: Connect two brake wheels’ wire into PC-board, and the signal wire into the receiver :. . Step 3: Set an action “ON/OFF” on your transmitter:. . Notice :The signal wire must connect into the working receiver,otherwise it will consume all the battery. Voltage input:. 7.2V-14.8V can tap directly on aircraft battery or use an external battery 7.2V-14.8V. Brake force control:. The transmitter only support ON/OFF, thus there is not making proportional brake, or you can use currency trim button to control the brake force.The controller shut down the brake after 1 minute. The controller will smartly detect it,shut down the current to brake system and automatically reset it to its normal function. This ‘auto-shut down’ is designed to protect the magnetic coil and conserve your battery power.
