Description PowerBox iGyro Sensor Switch, GPS-Sensor & USB interface adapter Product description The PowerBox iGyro™ SRS is a completely new type of gyro system intended for fixed-wing model aircraft. At the development stage our constant aim was to com-bine maximum versatility with simplicity of operation. The system incorporates a regulatory algorithm specifically developed for fixed-wing models, which causes hardly any alteration in the model’s familiar flying characteristics; at the same time the airplane flies much more smoothly and accurately, and is less sensitive to unwanted weather-induced or aerodynamic influences. The need for mixers, such as elevator to rudder or flaps, is eliminated entirely. The iGyro™ exploits the latest servo bus technology to minimize the extremely complex wiring arrangements necessitated by previous gyro systems. The ability to assign any channel to the gain adjusters makes it possible to set up the desired gyro effect accurately in just one short flight. Independent adjustment of each of the five outputs is possible, enabling the modeler to set up gyro gain and direction of effect precisely. The separate GPS sensor provides a means of obtaining a constant gyro effect over the model’s full speed range, effectively eliminating the problem of  over-compensation leading to oscillation in high-speed flight. In version 16 and later the software include a menu-based setup assistant which makes it possible to complete all the settings in just a few minutes. Features:     Extremely accurate triple-axis MEMS sensor     Special regulatory algorithm designed for fixed-wing model aircraft     Menu-based setup assistant     Three-stage flight phase switching     Three axes distributed to five servos, each adjustable independently     GPS-regulated gyro gain     Integral delta mixer     Can be installed in any attitude     Graphic OLED screen with 128 x 64 pixels     Ultra-simple menu-controlled programming method using the SensorSwitch     SRS technology for use with various bus systems:     Futaba S-Bus, Spektrum SRXL, DSM2/DSMX, JR DMSS, HoTT, M-Link and Jeti     Unrestricted channel assignment (channel mapping)     Digital output can be passed on to an SRS PowerBox system     16-bit processor for fast, high-resolution signal processing     Settings can be stored on a PC and reloaded at any time     Updateable with PowerBox Systems USB Interface connectors     Robust aluminium case Technical Data: Operating voltage  4.0V – 9.0V Current drain Power-on state  51mA Current drain, GPS  60mA Maximum load current  10A Signal input  serial Supported RC systems  Futaba, Spektrum, JR, Jeti, Graupner, Multiplex Receiver redundancy  SRS Servo sockets  5 Servo signal resolution  0,5µs Gyro regulation  Heading- and Normalmode Gyro sensor type  MEMS Number of sensor axes  3 Screen  OLED 128 x 64 pixels, graphic Dimensions  52 x 35 x 14 mm Weight  50g, incl. GPS Sensor Temperature range  -30°C to 75°C
