Description The all new MKS HBL6625 is our latest 10mm thick wing servo. This is a market first, bring Brushless motor technology into a 10mm thick wing servo! Once you have tried MKS, you will know you have tried the very best! Never has a glider servo been so accurate and tight! This is what we all have been searching for!! The HBL6625 has a full CNC Aluminum case that has been milled to the highest of tolerances. SKU  MKS-HBL6625 Dead Band  0.001 ms Control System  Pulse Width Control Working Frequence  1520μs / 333hz Operating Voltage  4.8~8.4 V DC Volts Operating Speed (6V)  0.16 sec/60° degrees at no load Operating Speed (7.4V)  0.127 sec/60° degrees at no load Operating Speed (8.4V)  0.11 sec/60° degrees at no load Stall Torque (6V)  8.2 Kg/cm (113.88 oz/in) Stall Torque (7.4V)  9.6 Kg/cm (133.32 oz/in) Stall Torque (8.4V)  10.4 Kg/cm (144.43 oz/in) Motor Type  Brushless Motor Potentiometer Drive  Direct Drive Bearing Type  Dual Ball Bearings Gear Type  Chrome-Titanium alloy gear Programmable  No Connector Wire Length  15.0 cm (5.89 in) Dimensions  30X10X35.5 mm (1.1811X0.39X1.39 in) Weight  27.85g See additional images for dimensions. Note: Not standard Futaba Spline.  Use DS6125 Arms. Note: All Standard and mini servos except the X8 range (HBL380, HBL850, HBL880) use a 6mm 25tooth spline, same as Futaba. Micro and wing servos all use a MKS 5mm spline.
