MKS HV6130H Thin Wing Digital Servo 112oz @ 8.4v .10/60deg
$ 76.05
Description MKS HV6130H Thin Digital Servo Dead Band 0.001 ms Control System Pulse Width Control Working Frequence 1520μs / 333Hz Operating Voltage 3.5~8.4 V DC Volt (2S Lipo un-regulated) Operating Speed (6V) 0.14 sec/60° degrees at no load Operating Speed (7.4V) 0.11 sec/60° degrees at no load Operating Speed (8.4V) 0.10 sec/60° degrees at no load Stall Torque (6V) 6 Kg/cm (83 oz/in) Stall Torque (7.4V) 7.6 Kg/cm (105.5 oz/in) Stall Torque (8.4V) 8.1 Kg/cm (112.5 oz/in) Motor Type Coreless Motor Potentiometer Drive Direct Drive Bearing Type 3x Ball Bearings 2x Jewel Bearing Gear Type Metal Alloy gear Dimensions 30x10x29.8 mm (1.1811X0.39X1.17 in) Weight 23g (0.81oz) See additional images for dimensions.
